Led Insert Round Indicator

AP10500. Amber/Indicator. Equivalent in dimension to the popular sealed lighting systems. These lamps offer a simple retro-fit to LED. Polycarbonate construction multi-volt circuitry and 40 LEDs per lamp ensure outstanding performance.

Lamps can be flush mounted into rubber grommets (AP10507) or a stainless steel flange (AP10506) to be bought separately.

Number of LEDs : 40

Lens Material : Polycarbonate

Bracket/Housing : ABS Plastic

Voltage : 10-30V

Current Draw : 0.18A

Barcode : 9333938000325

Grommet Hole Cut Out Diameter : 114mm, Light Diameter : 109mm, Height : 53mm.
If LOK 3 Pin Plug Is Required, Please Order AP10509.
