12 VOLT Wiper Motor TCM1233-76 Dia: 13.6/76 MM 2 SPEED SMALL SCREEN MARINE DYANMIC PARK
$73.34
We will send you an email to reset your password.
12 VOLT Wiper Motor TCM1233-76 Ø 13.6/76 MM 2 SPEED SMALL SCREEN MARINE DYANMIC PARK
Excellent small screen wiper motor.
This motor is suitable for marine use.
Available in 3 shaft lengths and 4 degree sweep options.
With the right switch you can enjoy 2 speeds, auto park and washer functions.
| TECHNICAL SPECIFICATIONS | |
|---|---|
| VOLTAGE | 12 VOLT/ 24 VOLT |
| TEST VOLTAGE | 13.5 VOLT / 27 VOLT |
| BRAKE TORQUE | 18Nm |
| WORKING TORQUE | 3.43Nm |
| NOISE | < 53dB(A) |
| NO-LOAD SPEED (LOW) | 33 ± 5RPM |
| NO-LOAD SPEED (HIGH) | 45 ± 7RPM |
| NO-LOAD CURRENT (LOW | < 2A (12V) <1A (24V) |
| NO-LOAD CURRENT (HIGH) | < 3A (12V) <1.5A (24V) |
| WORKING SPEED (LOW) | 30 ± 4RPM |
| WORKING SPEED (HIGH) | 40 ± 4RPM |
| WORKING CURRENT (LOW) | < 5A (12V) < 2.5A (24V) |
| WORKING CURRENT (HIGH) | < 7A (12V) < 3.5A (24V) |
| WIPER ANGLE | 45 - 110º |
| WIPER SPECIFICATIONS | BLADE 500mm ARM 500mm |
